FACILITY EQUIPMENT

Distribution storage

Nonn Family Farm · FARM-WI-NONN-01

Receiving container, paddle assembly and transfer route into the processing system.

Distribution storage summary

Working capacity: 2,500gal; User-supplied assumption
Current fill: Not recorded; No level reading available
Outlet: Inlet meter; Via the transfer pump
Registration: Configuration; Individual asset not yet registered

Nonn Family Farm · FARM-WI-NONN-01

Storage configuration

Initial distribution container

Rectangular receiving vessel with a horizontal paddle assembly.

Initial distribution storage container — Distribution storage Photo-based illustration · not a level reading

Working capacity: 2,500 US gal
Current fill: Not recorded
Outlet route: Transfer pump → inlet meter
Agitation: Horizontal framed paddles

The 2,500 US gal capacity is a working assumption, not a manufacturer rating or measured safe operating limit. Dimensions and an individual asset registration have not yet been recorded. This configuration is separate from registered-tank totals.

Processing replay

Fill follows the event transfer

Replay assumes a full 2,500-gallon start. The metered transfer is subtracted as the inlet phase progresses. No refill is assumed; a transfer beyond capacity is flagged.

This modeled remainder is not a saved inventory reading. Paddle speed, liquid movement and equipment proportions are illustrative.

Drawing geometry Provisional reference · configuration unchanged

Geometry reference

Drawing geometry reference r1 · 2026-10-15

Current native context: Initial distribution container
Record mapping: Individual distribution asset not established
Original units / basis: Inches · internal/external basis unconfirmed
Provenance: Supplied drawing dimensions transcribed in QA #15

This reference does not change saved dimensions, capacity, level readings or historical configuration. It is not a calibrated or usable-capacity result.

Drawing 3, upper sketch: dimension labels and endpoints remain unresolved. No numerical geometry or geometric capacity estimate is entered. The existing 2,500 US gal working assumption stays separate and unchanged.

Basis and activation limits

1 US gallon =231 cubic inches. Manure reference: πr² ×24 + πr² ×21.5 ÷3; rectangular reference:43 ×36 ×38. These use unconfirmed drawing dimensions. Operational activation needs confirmed measurement basis, truncation, axes, placement, level datum and existing-record relationship review. Saved configuration, sensor readings and historical calculations stay unchanged.
